Click Here for Spec Sheet

The SL29 Lanai Light is designed to provide clean architectural illumination in covered outdoor structures such as pool cages, lanais, pergolas, and beam structures. Its modern profile integrates seamlessly with structural elements while delivering balanced up and down lighting that enhances both the architecture and the space below.

With six adjustable lumen settings built into the driver, designers and installers can easily fine-tune the light output to achieve the desired effect for each project. Combined with exceptional color quality and marine-grade construction, the SL29 offers reliable performance in demanding outdoor environments.

Material: Marine-Grade, Virgin Brass with a powder coat finish
Finish: Antique Bronze
Adjustable lumen options: 656lm, 499lm, 386lm, 263lm, 158lm, 84lm
Certifications & Listings: ETL, UL1838, IP65 rated
Case Quantity: 10 Luminaires

Features

• Six selectable lumen settings allow precise adjustment of light output to match each project
• Single-source LED provides clean, focused up and down illumination for architectural elements
• Ideal for pool cages, lanais, pergolas, and structural beams
• Modern, compact profile designed to integrate cleanly with architectural structures
• Constructed with high quality CREE LED chips
• Light color temperature options of 2700K or 3000K
• Marine-grade brass construction for durability in coastal and outdoor environments
• 9–15V AC voltage range compatible with standard low voltage landscape lighting systems
• 1.2W (min) – 12.9W (max) adjustable power range
• Exceptional color performance with CRI 97+, TM-30 Rf 94, and TM-30 Rg 99

SL29 Adjustable Lumen Settings (Pins on Driver)

• 0 Pins Up: 656 lm (max)
• 1 Pin Up: 499 lm
• 2 Pins Up: 386 lm
• 3 Pins Up: 263 lm
• 4 Pins Up: 158 lm
• 5 Pins Up: 84 lm (min)
